- 10″ working width will scarify approximately 500-750 sq. ft. per hour at Depth Per Pass of 1/8″
- Adjustable depth control up to 3/16″ working depth per pass
- Upcut drum rotation and heavyweight construction increases production and lifts even the toughest floor coatings
- Hydrostatic transmission with forward and reverse drive provides smooth speed changes and less operator fatigue
- Includes lifting bail, oil alert and hour meter
- Optional outrigger axle enables the CPU-10(FC) to follow slab contours closely when working on uneven surfaces
- Convertible hood design on CPU-10(FC) allows for multiple drum set-ups and provides easy access for quick drum changes
SPECIFICATIONS
| Specification | CPU-10FC-E (Electric, Part #73600 / 73600-230) | CPU-10FC-G (Gasoline, Part #73400) |
|---|---|---|
| Model # | CPU-10FC-E (10″ Self-Propelled) | CPU-10FC-G (10″ Self-Propelled) |
| Part # | 73600, 73600-230 | 73400 |
| Engine / Motor | Electric (3-Phase) | Gasoline |
| Phase / Amps | 3-Phase / ~23.6 A (or 23 A variant) | — |
| RPMs | 2,179 | 2,122 |
| Length | 49 in (1,245 mm) | 49 in (1,245 mm) |
| Width | 25.5 in (648 mm) | 25.5 in (648 mm) |
| Height | 41 in (1,041 mm) | 42 in (1,067 mm) |
| Weight | 530 lbs (240 kg) | 530 lbs (240 kg) |
| Max Cord Length | 100 ft, 10 Gauge | — |
SHIPPING & SUPPORT
This product ships directly from EDCO U.S. manufacturing facility. Standard lead time is 5–7 business days to ship.
Have questions or need help choosing the right size or accessories?
Contact us at sales@trackram.com or call (307) 312-9468 — our team is here to help.
