Diamond Products WS25 Wire Saw showing a close-up of the diamond-coated wire and cutting mechanism in action.

Diamond Products WS25 Wire Saw

SKU 02248
by Diamond Products
$9,860.00 - $19,577.00
$17,976.00
$9,860.00 - $19,577.00
$17,976.00

✓ FREE Ground Shipping

✓ Backed by manufacturer's standard warranty

✓ Ships from distribution facility in Whites Creek, TN

✓ Built for commercial & jobsite use

ESTIMATED DELIVERY TIME

Order today for delivery in 7-10 business days.

Request a quote

The WS25 Wire Saw is a heavy-duty hydraulic cutting tool designed for unlimited depth cuts in concrete and similar materials. This saw is engineered for both vertical and horizontal operations, giving contractors maximum flexibility. With virtually no vibration or noise, it delivers fast, clean cuts while allowing for a wide variety of setups thanks to its modular design. Whether for precision architectural work or robust structural cutting, the WS25 offers strong performance, durability, and ease of use.

FEATURES & BENEFITS

  • No vibration or noise and fast cutting speed
  • Modular design provides infinite setup options
  • Universal clamps provide infinite orientation of idler wheels
  • Bases mount to concrete surface with anchor bolts

SPECIFICATIONS

Wire Speed: 0-5,000 ft/min-infinitely variable and reversible
Drive Motor: 6 ft. stroke driven by Danfoss 1.93 cubic inch hydraulic motor
Sawing Angle: Set up vertical or horizontal from the same frame
Drive Motor: Char-Lynn 9.9 cubic inch hydraulic motor 525 rpm @ 25 gpm
Drive Wheel: 32” diameter with neoprene lining in ‘V’ groove
Idler Wheels: 8”, 10” and 16” special polyethylene wheels with sealed bearings 8” idler adapts to the end of 2” pipe 10” and 16” idlers have 1-3/16” shaft for use with universal clamps
Pipe Mounting: For use with 2” schedule 80 pipe

Includes

  • (1) 8ft. column (1) 32” drive wheel,
  • (3) mounting bases (4) 16” idler wheels,
  • (2) universal clamps (1) 11ft. (1) 6ft
  • (3) 3ft. schedule 80 pipe sections
Description Part Number Catalog Number
WS25 Wire Saw for use with BS2 5800061 02248
Remote Control Unit for Hydrostress wall saws 5800112 48601
WS25 Wire Saw for use with Control Station 5800669 09484
WS25 Flush Cut Wire Saw for Use with BS2 5800621 50169
WS25 Flush Cut Wire Saw for Use with Control Station 5800622 39314
Wire Saw Control Station 5800059 02247
